19
Zoll 1HE Single CPU
Server Expert-2
| redundant
|
|

- Single AMD EPYC™ 4005/4004 &
Ryzen™ 9000 Series Processors
- Single Intel®
Xeon® 6300-Series/E-2400 Processors
- Dual Channel DDR5 ECC/Non-ECC UDIMM, 4 x DIMMs
- AMD EPYC™ 4005 /
Ryzen™ 9000:
UDIMM: Up to 5600 MT/s (1DPC), 3600 MT/s (2DPC)
AMD EPYC™ 4004:
UDIMM: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)
- Single Intel®
Xeon® 6300-Series/E-2400 Processors:
- UDIMM: Up to 4400 MT/s (1DPC), 4000 MT/s
(2DPC/1R),
- 3600 MT/s (2DPC/2R)
Single Intel®
Xeon® 6300-Series/E-2400 Processors:
- 2 x 1Gb/s LAN ports via Intel®
I210-AT
AMD EPYC™ 4004/4005 &
Ryzen™ 9000
2 x 1Gb/s LAN ports via Broadcom® BCM5720
- 2 x 2.5" SATA hot-swap bays
- 1 x M.2 slot with PCIe Gen4 x4 interface
Single Intel®
Xeon® 6300-Series/E-2400 Processors:
- 1 x FHFL PCIe Gen5 x16 or 2 x FHFL PCIe Gen5 x8
slots
- 1 x FHHL PCIe Gen4 x4 slot
AMD EPYC™ 4004/4005 &
Ryzen™ 9000
- 1 x FHFL PCIe Gen5 x16 slot
- 1 x FHHL PCIe Gen4 x4 slot
- 1+1 800W 80 PLUS Titanium redundant power
supplies
- Dimensions (WxHxD, mm) 438 x 43.5 x
520
|
|
|
